柴油機 |
額定功率: |
160kw |
額定轉速: |
3800rpm |
缸徑: |
94mm |
沖程: |
100mm |
認證: |
IMO-NOx requirements of the International Maritime Organization(IMO),MARPOL 73/78Annex VI,Regulation 13 EPA Tier2-Model year requirements of the EPA marine regulation(40CFR94) |
排量: |
2.8L |
配置: |
D933002MX03 |
進氣方式: |
Turbocharged/Sea Water Aftercooled |
最大扭矩: |
485N.M(轉速為2600rpm下的最大扭矩) |
壓縮比: |
17.5 |
額定扭矩: |
401N.M |
廢氣排溫: |
527℃(Turbine out)/671℃(Manifold) |
廢氣體積流量: |
496L/S |
平均效應壓力: |
1816kPa(Brake) |
點火順序: |
1-3-4-2 |
活塞速度: |
12.7m/s |
燃油系統: |
Bosch Common Rail(CRS2.0) |
冷卻系統: |
水冷 |
重量: |
360kg |
燃油消耗: |
50l/hr |
缸數: |
4 |
馬力: |
220mhp |
