智能數字型大氣壓力變送器 | |||
類型: | 壓力式 | 測量對象: | 液體 |
測量目標: | 氣壓補償/壓力 | 信號轉換: | 模擬信號/數字信號 |
數值類型: | 絕對值 | 最大量程: | 1.2Bar |
超負荷量程倍數: | 2 | 量程定制: | 不可定制 |
量程比: | 3 | 最小量程: | 0.8Bar |
性能亮點: | Robust all welded weatherproof and submersible construction ; Choice of Sealed cable connection or DIN Plug for either fully submersible installation or the installation site which does not require the fully protection of submersible construction; Can be also uesd as a stand-alone instrument for Barometric pressure measurement for other applications; | 輸出信號: | 4-20mA/ RS485 Modbus RTU |
脹裂壓力: | 15 x Nominal range | 精度: | 0.1% |
供電電壓: | 10 ~ 30V DC | 反接保護: | Yes |
工作溫度: | -20 ~ +85°C | 溫度補償: | 0 ~ 70°C |
本體材質: | 316L Stainless Steel or Titanium | 防護等級: | IP68 |
國際防爆認證: | IECEx ITS 19.00023X Ex ia IIC T4 Ga -35℃≤Ta≤+85℃ | 歐洲防爆認證: | ITS19ATEX204962X Iss.0 Ex ia IIC T4 Ga -35℃≤Ta≤+85℃ |
變送器方向: | NA |
-供應商聯系方式- | |||||
![]() |
公司名稱: | PSM Instrumentation Ltd |
![]() |
聯系人姓名: | Mark Jones |
公司地址: | Unit 3 Burrell Road, Haywards Heath, West Sussex, UK. RH16 1TW | 聯系人電話: | +44(0)1444410040 | ||
聯系人郵箱: | mark.jones@psmmarine.com |
